BSD Radar Warning System For Trucks
![](http://v4-upload.goalsites.com/625/1717494480_BSD-product.png)
![](http://v4-upload.goalsites.com/625/1717494592_BSD-Feature.jpg)
01 Specification
Item | Parameter |
Operating frequency | 77GHz |
Detection range on both sidesof the body | 3m |
Vehicle rear detection range | 80m |
Horizontal angle | 120° |
Update target rate | 33Hz |
Detection range accuracy | 0.36m |
Detection angle error ange | 1° |
Detect the relative velocity error range | ±0.25 m/s |
Operation voltage | 9V-16V |
Power Consumption | <300mA(Single) |
Operation Temperature | -40℃~+85℃ |
Storage Temperature | -40℃~+85℃ |
IP Rating | IP 68 |
02 Function
Blind spot detection
Note: As the below photo, the shadow parts will be the detection area. As the car driving the same direction with car 1, there is a car approaching in the part 2 or part 3, the system will have a sound or LED flash alert. (Blind area detection range is 3M of the backside of your car).
Lane change assistant
Note: As shown on the left, the areas 2&3 of the shadow parts are the lane changing function areas.If there are vehicles coming the same direction as the car 1 and getting closer to the car 1 in the area 2 or 3, the system will beep and the LED light will flash to give a warning. The farthest detectable distance is 15M behind the car.
![](http://v4-upload.goalsites.com/625/1717495329_BSD-function.jpg)
![](http://v4-upload.goalsites.com/625/1717495382_BSD-location.jpg)
03 Feature
1. 77G HZ high performance microwave sensor
2. Open door early warning function
3. LED light alarm, Sound alarm, Double security
4. All-day work, not affected by the weather
5. Detect 3*80m long distance and wide area behind the car
6. No need to pierce holes, does not affect the appearance of the car
